Code 3 MICROPAK Series 6-LED Low-Profile Warning Light

The Code 3 MICROPAK is a slim, low-profile 6-LED warning light that surface mounts or flush mounts through a 1-inch hole. It packs bright warning into a 1.3-inch footprint for grilles, push bumpers, mirrors and body panels. Single-color, dual-color and Code 3 Connect versions are offered, along with an optional L-bracket.

Features

• Six powerful LEDs in a slim, low-profile design
• All controls built into the module
• Optimized lens and optics for maximum output
• Flush mounts in a 1" hole with a pigtail lead
• Steady burn and dimmable
• Code 3 Connect plug-and-play versions available
• Matrix compatible: can be controlled and synchronized through a Code 3 Z3S siren or Switch Node
• Syncs with other Code 3 warning lights in the same sync group when set to matching flash patterns

Specifications

• Voltage: 12-24V
• Current: 1.2A (single-color), 0.6A (dual-color)
• Flash patterns: 29 (single-color), 69 (dual-color)
• Colors: Amber, Blue, Green, Red, White; dual-color Amber/Green, Amber/White, Blue/Amber, Blue/White, Red/Amber, Red/Blue, Red/White
• Dimensions: 1.3" H x 1.3" L x 1.4" D
• Certifications: SAE J595 Class 1, California Title 13, ECE R10, ECE R65, IP67, IP69K
