Code 3 MR6 Series LED Multi-Mount Warning Light

The MR6 (and quad-color MR24Q) are versatile multi-mount warning lights with strong straight-on and off-angle output. Included brackets let them go nearly anywhere on police, fire and EMS vehicles, in single-, dual- or quad-color configurations.

Features

• Single-color models use Total Internal Reflector (TIR) optics; all models use linear optic LEDs
• Phase 1 and phase 2 sync with multiple flash patterns
• Black powder-coated metal housing
• Brackets included for surface mount or edge mount with adjustable 30-degree pivot
• Syncs with XTP, Mega Thin, Chase, M180, MICROPAK, CD5051, HB12PAK and CD9215 lights
• Steady-burn (-SB) models

Specifications

• Voltage: 12-24V
• Current: 0.9A (single-color), 1.25A (dual-color)
• Flash patterns: 29 (single-color), 69 (dual-color)
• Colors: Amber, Blue, Green, Red, White; dual-color Amber/Green, Amber/White, Blue/Amber, Blue/White, Red/Amber, Red/Blue, Red/White; quad-color Red/Blue/Amber/White (MR24Q)
• Dimensions: 1.2" H x 5.2" L x 0.8" D
• Mounting hole spacing: 4.74"
• Certifications: SAE J595 Class 1 (except green), California Title 13 (amber, blue and red only), CE, UKCA, ECE R10, ECE R65 (amber, blue and red only), IP67, IP69K, RoHS
• Certifications vary by color; see the spec sheet for your model.
