STI-CO RFMT-HFNMO-6/7200 5G Ultra Wideband Antenna - White

A low-profile ultra-wideband antenna in a white radome covering 600 MHz to 7.2 GHz for 5G, LTE, FirstNet Band 14, CBRS and Wi-Fi 6E. One rugged antenna for public safety, transit, rail, military and IoT fleet vehicles.

Features

• Covers 5G NR FR1, LTE Band 14, CBRS, Wi-Fi 6E and Bluetooth
• Compact 3.62" height on an HF-NMO base
• Designed to MIL-STD-810, AREMA, IPX7 and SAE J1455
• Rated -60 °F to +158 °F
• Made in the U.S.A.; 5-year warranty

Specifications

• Part number: RFMT-HFNMO-6/7200 (white – confirm color suffix with STI-CO)
• Frequency range: 600-960 / 1700-7200 MHz
• Gain: 2.91 / 7.66 dBi
• VSWR: <3:1 / <2.5:1
• Connector: HF-NMO
• Mount: NMO (5/8" hole)
• Dimensions: 3.62" H x 1.67" dia.
